6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint

6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint
6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint 6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint

Large Image :  6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint

Product Details:
Place of Origin: Henan,China
Brand Name: Liang He
Certification: ISO 9001
Model Number: KXT
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $3.5-35.63 per set
Packaging Details: cartons,wooden cases
Delivery Time: 1-3 work days
Payment Terms: T/T, D/A, D/P, Western Union, MoneyGram, L/C
Supply Ability: 10000 pieces per Month
Contact Now Chat Now

6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint

Description
Technics: Forged Warranty: 1 Year
Working Temperature: -20℃~150℃ Working Pressure: 1.0-2.5Mpa
Size: DN32-DN3000 Customized Support: OEM
Connect: Flange Flange Material: NR，NBR，EPDM
Manufacturer: Yes
Highlight:

epdm flexible rubber expansion joint

,

6 inch epdm bellows expansion joint

,

6 inch flexible rubber expansion joint

6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint
6 inch carbon steel flange EPDM rubber bellows flexible rubber joint
Single ball rubber joint suitable for media
  • Water (domestic sewage)
  • Industrial sewage
  • Petroleum
  • Chemical raw materials
  • Lime mortar
  • Food, beverage, etc.
Performance characteristics of single ball rubber joint
  • Small size, light weight, good flexibility, easy installation and maintenance.
  • The installation can produce transverse, axial, angular displacement, not by the pipe through the heart, flange unparallel restrictions.
  • The work can reduce the structure transmission noise, strong vibration absorption ability.
Rubber joint material table
6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint 0
NO NAME Material
1 Outer/inner rubber EPDM, NR, NBR
2 Frame Nylon cord
3 Pressurized ring Steel wire or stainless steel
4 Flange SS304, SS316, carbon steel, ductile iron, etc
Main connection size
Nominal Length Axial displacement(mm) Horizontal displacement(mm) Deflection angle
mm inch Elongation Compression
32 1 1/4 95 6 9 9 15°
40 1 1/2 95 6 10 9 15°
50 2 105 7 10 10 15°
65 2 1/2 115 7 13 11 15°
80 3 135 8 15 12 15°
100 4 150 10 19 13 15°
125 5 165 12 19 13 15°
150 6 180 12 20 14 15°
200 8 210 16 25 22 15°
250 10 230 16 25 22 15°
300 12 245 16 25 22 15°
350 14 255 16 25 22 15°
400 16 255 16 25 22 15°
450 18 255 16 25 22 15°
500 20 255 16 25 22 15°
600 24 260 16 25 22 15°
700 28 260 16 25 22 15°
800 32 260 16 25 22 15°
900 36 260 16 25 22 15°
1000 40 260 18 26 24 15°
Product superiority
6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint 1
Inventory display
6 Inch Carbon Steel Flange EPDM Bellows Expansion Joint / Flexible Rubber Expansion Joint 2
FAQ
Q: Do you have a catalogue?
A: Yes, we do. Please tell me your email address or instant message and we will send our catalog.
Q: Do you provide samples? Is it free or paid?
A: Yes, we can provide samples free of charge, but the freight is borne by the customer.
Q: Can we choose different materials?
A: Yes, we can choose the material according to your requirements.
Q: What is your delivery time?
A: It depends on the quantity, but usually does not exceed 20 working days.
